---------------------- multipart/mixed attachment --Boundary_(ID_gZQYeRlS1hN80IJH87sDQw) Sorry, It's a Hohner Clavinet D-6. , a classic keyboard... Arguably the most successful keyboard ever produced by German Company,=20= Hohner, was the Clavinet. Hohner, known mainly for their reed=20 instruments (harmonicas, melodicas etc.) had previously made several=20 major contributions to the classic keyboard "Hall of Fame." Musician and inventor, Ernst Zacharias, designed the first of these,=20 the Cembalet, in the 1950=92s. This was intended to be a portable,=20 amplifiable version of the Cembalo, or Harpsichord. This worked by=20 plucking the end of a flat reed with the key, which was then picked up=20= and amplified in much the same way as an electric guitar. A little=20 later came the Pianet. Both the "CH" and "N" models once again used=20 flat reeds, but employed a very different plucking/striking action.=20 When a key was depressed it engaged a "sticky pad" with foam backing=20 which actually stuck to the reed. When the key was released, the pad=20 came unstuck causing the reed to vibrate which was then amplified. The=20= Pianet model "T" came much later and utilized the suction of a soft=20 rubber pad onto the reed. This was somewhat superior to the "N" and=20 "CH" models, but still had several drawbacks. Although made very=20 popular by bands such as the Zombies and Small Faces, there wasn=92t = much=20 dynamism available from the keyboard. As all the reeds were damped upon=20= release, this negated the possibility of obtaining sustain via a foot=20 pedal. In between the Pianet "N" and "T" models, Zachariah invented what was=20 to become probably Hohner=92s most successful, and certainly funkiest=20 keyboard - The Clavinet. Essentially designed to replicate the sound of=20= a Clavichord without the Clavichord=92s inherent wimpiness, the Clavinet=20= was an amazing success. The early models - Clavinet I with inbuilt amp,=20= Clavinet II with tonal filters, Clavinet "L" with it=92s bizarre=20 triangular shape, all led to the Clavinet model "C". This, in turn, was=20= refined into the D6 - a portable, amplifiable keyboard. This had a=20 fully dynamic keyboard (see fig.2) - as the striker is directly=20 underneath the key, the harder you hit, the louder and more vibrant the=20= tone. (Of course, if you hit too hard you=92ll split the striker pads=20 converting the Clav into a Cembalo!!) Mention the Clavinet today and most people will automatically think of=20= Stevie Wonders "Superstition" - a recording that owes as much to the=20 instrument played upon it, as it does to the artist that wrote and=20 performed it. The D6 was later superseded by the model E6 and the=20 Clavinet/Pianet Duo. These were basically the same, but more roadworthy=20= and better protected against proximity hums and generally quieter than=20= previous models. However, these models came just a bit too late on the=20= scene in the age of electronics to be as successful as they deserved to=20= be. With all of these instruments enjoying a resurgence in popularity a few=20= words of advice about purchasing would not go astray. Realistically,=20 the Black models are the best to purchase in both the Pianet and the=20 Clavinet. The Pianet "T" has a superior striker system and is a lot=20 more roadworthy. The Clavinet E6 is quieter in background noise and=20 once again more robust. Although noisy, the Cembalet is fine as it is,=20= as there are not a lot of moving parts to wear out. A word of warning=20 on the Clavinet however, as there are NO spare parts available on an=20 International basis. Do not pay much for a Clav unless it has been=20 rebuilt. Although guitar strings can be used, their amplitude and tonal=20= qualities are not the same. You also have to join strings together to=20 get the correct length for the lower strings. Striker pads are no=20 longer available and any that are still floating around are generally=20 unusable because of oxidization and perishment problems. Hohner will=20 not be making any themselves because of small production volumes=20 elevating the price out of viability. At present no other way exists to repair Clavs that I am aware of,=20 other than dipping the entire keyboard assembly in a plasticized rubber=20= compound, allowing this to cure and then painstakingly shaping each=20 single striker by hand. Although this is effective, it is an extremely=20= time consuming business and very costly for a professional to=20 undertake. When buying a Clav privately, check the interior for=20 oxidization and in particular, check the strikers. When a key is=20 pressed down firmly and held for a second there should be no=20 discernible plucking or "sticking" of the pad to the string. A Clav=20 that=92s been played by a meatfist will probably have split strikers,=20 i.e.: the pad splits in the center and slips down each side of the=20 string like a claw making the Clav essentially unplayable. Like all electromechanical keyboards there is nothing that sounds and=20 plays like a Clav - it actually makes one feel like playing it and it=20 is an absolute pleasure to use live. If you do find a good one=20 somewhere, don=92t hesitate to purchase it - this is a usable, fantastic=20= sounding, funky little keyboard. You won=92t regret it. Still widely used in rock and "r & b" today. A music industry standard. LASSIC KEYBOARDS - THE HOHNER CLAVINET Reproduced from Article in Australian M= --Boundary_(ID_gZQYeRlS1hN80IJH87sDQw) A non-text attachment was scrubbed... Name: not available Type: text/enriched Size: 5494 bytes Desc: not available Url : https://www.moypiano.com/ptg/pianotech.php/attachments/77/4a/b3/04/attachment.bin --Boundary_(ID_gZQYeRlS1hN80IJH87sDQw)-- ---------------------- multipart/mixed attachment A non-text attachment was scrubbed... Name: clavdiag.jpg Type: image/jpeg Size: 49783 bytes Desc: not available Url : https://www.moypiano.com/ptg/pianotech.php/attachments/21/64/65/1b/clavdiag.jpg ---------------------- multipart/mixed attachment --Boundary_(ID_avLaDk03zMzObU4LZUld8w) usician Magazine1997 by Brad Coates the most successful keyboard ever produced by German Company, Hohner, was the Clavinet. Hohner, known mainly for their reed instruments (harmonicas, melodicas etc.) had previously made several major ntributions to the classic keyboard "Hall --Boundary_(ID_avLaDk03zMzObU4LZUld8w) A non-text attachment was scrubbed... Name: not available Type: text/enriched Size: 480 bytes Desc: not available Url : https://www.moypiano.com/ptg/pianotech.php/attachments/07/58/1f/13/attachment.bin --Boundary_(ID_avLaDk03zMzObU4LZUld8w)-- ---------------------- multipart/mixed attachment A non-text attachment was scrubbed... Name: pianet.jpg Type: image/jpeg Size: 47432 bytes Desc: not available Url : https://www.moypiano.com/ptg/pianotech.php/attachments/46/62/a2/24/pianet.jpg ---------------------- multipart/mixed attachment --Boundary_(ID_1DNiim0eC4k4eNlAbqZq6g) of Fame." --Boundary_(ID_1DNiim0eC4k4eNlAbqZq6g) A non-text attachment was scrubbed... Name: not available Type: text/enriched Size: 134 bytes Desc: not available Url : https://www.moypiano.com/ptg/pianotech.php/attachments/b4/f6/5a/1c/attachment.bin --Boundary_(ID_1DNiim0eC4k4eNlAbqZq6g)-- ---------------------- multipart/mixed attachment A non-text attachment was scrubbed... Name: cembalet.jpg Type: image/jpeg Size: 45195 bytes Desc: not available Url : https://www.moypiano.com/ptg/pianotech.php/attachments/37/ac/b5/8c/cembalet.jpg ---------------------- multipart/mixed attachment --Boundary_(ID_pHmq6RqbVCcCYuAT7H39mA) Musician and inventor, Ernst Zacharias, designed the first of these,=20 the Cembalet, in the 1950=92s. This was intended to be a portable,=20 amplifiable version of the Cembalo, or Harpsichord. This worked by=20 plucking the end of a flat reed with the key, which was then picked up=20= and amplified in much the same way as an electric guitar. A little=20 later came the Pianet. Both the "CH" and "N" models once again used=20 flat reeds, but employed a very different plucking/striking action.=20 When a key was depressed it engaged a "sticky pad" with foam backing=20 which actually stuck to the reed. When the key was released, the pad=20 came unstuck causing the reed to vibrate which was then amplified. The=20= Pianet model "T" came much later and utilized the suction of a soft=20 rubber pad onto the reed. This was somewhat superior to the "N" and=20 "CH" models, but still had several drawbacks. Although made very=20 popular by bands such as the Zombies and Small Faces, there wasn=92t = much=20 dynamism available from the keyboard. As all the reeds were damped upon=20= release, this negated the possibility of obtaining sustain via a foot=20 pedal. In between the Pianet "N" and "T" models, Zachariah invented what was=20 to become probably Hohner=92s most successful, and certainly funkiest=20 keyboard - The Clavinet. Essentially designed to replicate the sound of=20= a Clavichord without the Clavichord=92s inherent wimpiness, the Clavinet=20= was an amazing success. The early models - Clavinet I with inbuilt amp,=20= Clavinet II with tonal filters, Clavinet "L" with it=92s bizarre=20 triangular shape, all led to the Clavinet model "C". This, in turn, was=20= refined into the D6 - a portable, amplifiable keyboard. This had a=20 fully dynamic keyboard (see fig.2) - as the striker is directly=20 underneath the key, the harder you hit, the louder and more vibrant the=20= tone. (Of course, if you hit too hard you=92ll split the striker pads=20 converting the Clav into a Cembalo!!) Mention the Clavinet today and most people will automatically think of=20= Stevie Wonders "Superstition" - a recording that owes as much to the=20 instrument played upon it, as it does to the artist that wrote and=20 performed it. The D6 was later superseded by the model E6 and the=20 Clavinet/Pianet Duo. These were basically the same, but more roadworthy=20= and better protected against proximity hums and generally quieter than=20= previous models. However, these models came just a bit too late on the=20= scene in the age of electronics to be as successful as they deserved to=20= be. With all of these instruments enjoying a resurgence in popularity a few=20= words of advice about purchasing would not go astray. Realistically,=20 the Black models are the best to purchase in both the Pianet and the=20 Clavinet. The Pianet "T" has a superior striker system and is a lot=20 more roadworthy. The Clavinet E6 is quieter in background noise and=20 once again more robust. Although noisy, the Cembalet is fine as it is,=20= as there are not a lot of moving parts to wear out. A word of warning=20 on the Clavinet however, as there are NO spare parts available on an=20 International basis. Do not pay much for a Clav unless it has been=20 rebuilt. Although guitar strings can be used, their amplitude and tonal=20= qualities are not the same. You also have to join strings together to=20 get the correct length for the lower strings. Striker pads are no=20 longer available and any that are still floating around are generally=20 unusable because of oxidization and perishment problems. Hohner will=20 not be making any themselves because of small production volumes=20 elevating the price out of viability. At present no other way exists to repair Clavs that I am aware of,=20 other than dipping the entire keyboard assembly in a plasticized rubber=20= compound, allowing this to cure and then painstakingly shaping each=20 single striker by hand. Although this is effective, it is an extremely=20= time consuming business and very costly for a professional to=20 undertake. When buying a Clav privately, check the interior for=20 oxidization and in particular, check the strikers. When a key is=20 pressed down firmly and held for a second there should be no=20 discernible plucking or "sticking" of the pad to the string. A Clav=20 that=92s been played by a meatfist will probably have split strikers,=20 i.e.: the pad splits in the center and slips down each side of the=20 string like a claw making the Clav essentially unplayable. Like all electromechanical keyboards there is nothing that sounds and=20 plays like a Clav - it actually makes one feel like playing it and it=20 is an absolute pleasure to use live. If you do find a good one=20 somewhere, don=92t hesitate to purchase it - this is a usable, fantastic=20= sounding, funky little keyboard. You won=92t regret it. On Mar 25, 2005, at 6:57 PM, Avery Todd wrote: > What is a "Hohner Calvinet D-6?" Sorry, I've never heard of that=20 > before. > > Avery Todd > > At 12:20 PM 3/25/05, you wrote: >> Hello List. >> >> I received a call today from a customer who has two broken strings on=20= >> a Hohner Calvinet D-6. >> Can someone please advise what type of wire or strings are needed to=20= >> replace C5 and A#5. >> If my memory serves me correctly they look similar to guitar strings. >> Any advice would be greatly appreciated. >> >> Thanks, >> >> Aart Markenstein >> >> Aart in America Piano Services >> 201-406-2594 >> >> _______________________________________________ >> pianotech list info: https://www.moypiano.com/resources/#archives > > > _______________________________________________ > pianotech list info: https://www.moypiano.com/resources/#archives > --Boundary_(ID_pHmq6RqbVCcCYuAT7H39mA) A non-text attachment was scrubbed... Name: not available Type: text/enriched Size: 5905 bytes Desc: not available Url : https://www.moypiano.com/ptg/pianotech.php/attachments/ce/42/d6/72/attachment.bin --Boundary_(ID_pHmq6RqbVCcCYuAT7H39mA)-- ---------------------- multipart/mixed attachment--
